ST-109 waterproof series high current manual reset overload protector for mobile socket converter DC motor small motor battery audio
Home / Product / Waterproof series resettable overload protector / ST-109 Waterproof Protector / ST-109 waterproof series high current manual reset overload protector for mobile socket converter DC motor small motor battery audio
ST-109 waterproof series high current manual reset overload protector for mobile socket converter DC motor small motor battery audio

ST-109 waterproof series high current manual reset overload protector for mobile socket converter DC motor small motor battery audio

  • Technical parameter:
    1. Rated current (A): minimum 10A, maximum 30A
    2. Working voltage (V): minimum 12V, maximum 250V
    3. AC and DC dual use
    Scope of use: used for multi-functional protection occasions such as computer sockets, combined sockets, power converters, instruments, multi-functional motor sockets, small generators, etc.
    This product series has passed CQC certification
    Existing Specifications: 30A Customized Specifications: 10A, 20A, 25A, 30A
  • st-109
  • zw1-12
  • Product description
Custom processing:  no Item number:  ST-109 Metal Thread 10-20A Bakelite, Composite Silver Brand: Cray
Model: ST-109 Metal Thread 10-20A Bakelite, Composite Silver  Type: Overcurrent protector Use:  Mobile sockets, converters, combination sockets
Volume: small Voltage characteristics: low pressure Shape: Insert
Fusing speed: T/slow Implementation standard: GB Automatic reset function: none
Maximum voltage: 250 （V） Maximum current: 10A-30A（A） Holding current: 10A-30A（A）
Operating temperature: 280 (℃) Temperature control range: -5/+40（℃） Whether cross-border export special supply source: no
